JNH series -- Sand injection molding machine with up and down sand shooting
The JNH Top and Bottom Auto sand injection molding machine is a servo-driven, high-pressure automatic molding solution designed to deliver superior mold quality for a wide range of casting requirements. Incorporating a top-and-bottom blow system, this Sand injection molding machine and support machineryachieves uniform sand compaction from both directions, effectively eliminating shadow effects and improving the surface finish of complex castings.
Available in single- or double-station configurations, the JNH series (Big size Sand injection molding machine) features a rigid four-column structure for enhanced stability and an intuitive human-machine interface (HMI) for easy operation and process control. Key molding parameters such as extrusion pressure, mold height, and forming speed are fully adjustable to meet varying production needs.
By combining high-pressure hydraulic compaction, servo-controlled sand shooting, and automated mold ejection, the JNH series (sand injection blow molding machine) offers a reliable, efficient, and operator-safe molding process ideal for high-volume, precision casting environments.
1. Top and Bottom Sand Shooting System – Dual-directional sand blowing of the vertical sand injection molding machine ensures uniform filling and compactness throughout the mold, enhancing mold surface hardness and casting precision.
2. High-Pressure Hydraulic Compaction – Adjustable hydraulic pressure enables fine-tuned control over mold density, ensuring consistent quality across castings of varying complexity.
3. Servo-Controlled Operation – Advanced servo systems provide precise control over shooting and compaction processes, optimizing performance and energy efficiency.
4. Adjustable Mold Height and Squeeze Speed – Mold height and forming speed can be modified to accommodate a variety of casting specifications while minimizing sand usage.
5. Four-Column Rigid Frame – The machine’s robust structure ensures high precision and stability during high-speed operation.
6. User-Friendly HMI Interface – Centralized touchscreen controls allow for parameter setting, real-time monitoring, troubleshooting, and maintenance support.
7. Automated Blowout and Mold Ejection System – Streamlined hydraulic systems automate mold release and transition to the pouring line, improving production flow.
8. Lubricated Guide Columns – Integrated lubrication reduces wear and maintains alignment accuracy, extending machine lifespan.
9. Operator Safety Features – The control panel is positioned outside the machine’s operating zone and equipped with safety light guards to protect personnel during operation.
Product Parameter
JNH series --Sand injection molding machine with up and down sand shooting
| Model | Mold Size | Mold Height from (Cope) | Mold Height to (Drag) | Average Maximum Mold Rate (without Core setting) | Molding System |
|---|---|---|---|---|---|
| JNH3545 | (300~380)*(400~480)mm | 130~250mm | 130~250mm | 26 seconds/mold (without core-setting time) | Edge Blow + Squeeze |
| JNH4555 | (400~480)*(500~580)mm | 130~250mm | 130~250mm | 26 seconds/mold (without core-setting time) | Edge Blow + Squeeze |
JNH5565 | (500~580)*(600~680)mm | 130~250mm | 130~250mm | 26 seconds/mold (without core-setting time) | Edge Blow + Squeeze |
JNH6575 | (600~680)*(700~780)m | 130~250mm | 130~250mm | 26 seconds/mold (without core-setting time) | Edge Blow + Squeeze |
JNH7585 | (700~780)*(800~880)mm | 130~250mm | 130~250mm | 26 seconds/mold (without core-setting time) | Edge Blow + Squeeze |
Description
1. High-Speed Molding: The sand injection molding machine boasts a high-speed molding capability of up to 26 seconds per mold, without the need for additional core setting time, significantly increasing production efficiency.
2. Up and Down Sand Shooting Technology: The high pressure auto sand injection molding machine equipped with vertical sand shooting technology, it is best suited for deep-pocket patterns to effectively eliminate shadowing, ensuring the quality of the castings.
3. Squeeze Pressure Balance Control: The squeeze pressure balance control ensures stable molding and prevents pattern distortion, enhancing the precision of the castings.
4. Mold Height Feedback Control: The mold height feedback control system reduces sand consumption and compensates for compaction variations, optimizing sand usage.
5. User-Friendly Operation: The high pressure sand injection blow molding machine features a touch screen panel for easy operation, improving user-friendliness and reducing the difficulty of operation.
Product detail
1. Revolutionary Bidirectional Sand Injection Technology
Our vertical sand injection molding machine features a groundbreaking up and down sand shooting way. This dual-directional injection system simultaneously propels sand from the top and bottom, ensuring unparalleled density uniformity and eliminating voids in even the most complex patterns. This advanced method is the core of our auto sand injection molding machine, guaranteeing flawless mold integrity and superior casting quality for intricate designs.
2. Fully Automated, High-Capacity Production Cell
This auto sand injection molding machine is designed for unmanned, high-volume production. The integrated PLC system automates the entire cycle: flask positioning, precision up and down sand shooting, high-pressure compaction, and mold ejection. This system serves as the central unit in a complete line of sand injection molding machine and support machinery, seamlessly integrating with automatic pouring systems and conveyor lines for a turnkey foundry solution.
3. Engineered for Large-Scale, Precision Molding
As a big size sand injection molding machine, this model is built to handle massive molds with dimensions up to 1200x900mm and beyond. The powerful up and down sand shooting way provides the necessary force to achieve consistent hardness (92-95 HB) throughout these large molds, making it ideal for producing heavy-duty castings like engine blocks, machine tool beds, and industrial pump housings with absolute dimensional accuracy.
4. Robust Industrial Design for Foundry Durability
This machine is engineered as heavy-duty industrial foundry equipment. Its reinforced steel frame, tungsten-carbide injection nozzles, and industrial-grade hydraulics are built to withstand 24/7 operation under the most demanding conditions. The robust construction ensures exceptional reliability, minimal downtime, and a long operational lifespan, protecting your investment and maximizing productivity.
5. Comprehensive Support and Versatile Applications
We provide more than just a machine; we offer a complete package of sand injection molding machine and support machinery. This includes technical installation, operator training, and readily available spare parts. The machine’s versatility, akin to a sand injection blow molding machine in its precision, makes it perfect for automotive, aerospace, and heavy machinery sectors requiring high-integrity castings.
Global Reach & Industry Leadership
With a state-of-the-art manufacturing facility spanning over 10,000 square meters, JUNENG has firmly established itself as an industry leader. Our sand injection blow molding machine are trusted by customers in over 20 countries, including the United States, Brazil, India, Russia, and Vietnam. Our global reach is further supported by a network of authorized agents and sales offices, ensuring that we can deliver localized service and technical support to all our international clients.
In addition to providing high-quality vertical sand injection molding machine , JUNENG maintains a dedicated after-sales service system designed to offer timely technical support and assistance. Whether through direct service centers or our authorized partners, we are committed to creating lasting value for our customers and ensuring the seamless operation of their sand injection molding machine.
